PPR Pipe Extrusion Machine with Multi-Layer Control for Uniform Wall Thickness and 150kg/h Max Output

Extrusion Speed : 2-15m/min

Packaging Details : NORMAL PACKAGE

Installationtype : Floor Mounted

Brand Name : LB

Screw Design : Single-screw

MOQ : 1 SET

Payment Terms : L/C,T/T

Production Speed : 12m/min; 20m/min; 28m/min

Model Number : LB-63

Screwdiameter : 45mm - 65mm

Extruder Model : 6533

Plastic Processed : PP PE PPR materials

Machinelength : 15-20 meters

Certification : CE/ISO

Heating Concept : ELECTRIC HEATER

Delivery Time : 45 WOKING DAYS

Electrical Components : or Schnider

Place of Origin : ZHANGJIAGANG

Max Output : 150kg/h

After Sales Service : Engineer Overseas Service

Price : Negotiable（USD EUR）

Supply Ability : 15 SETS PER MONTH

Contact Now

PPR Pipe Extrusion Machine With Multi-Layer Control For Stripe Alignment And Uniform Wall Thickness

Extrusion Process

Multi-layer pipes are produced using co-extrusion pipe line technology. This specialized manufacturing process reduces raw material costs while creating pipes with enhanced functional characteristics.

For example, recycled materials can be used as the middle layer in PE thick wall pipes to optimize costs. For hot water supply applications, the production line incorporates PP-R layers along with additional structural layers such as glass fiber, providing superior performance characteristics.

Complete Extrusion Line Components

Single screw extruder
Co-extruder: For manufacturing marking lines on pipes or creating multi-layer pipes
Die head
Vacuum tank: Designed with single or double vacuum chambers based on diameter requirements
Cooling tank: Configured with one, two, or three tanks depending on diameter
Haul-offs: Available in double, three, four, six, eight, ten, or twelve haul-offs configurations based on diameter
Cutter: Options include no-scraps cutter or planetary cutter designs
Coiler/Tipping chute

Specifications

Model	Pipe Diameter (mm)	Extruder	Extruder Power (kw)	Capacity (kg/hr)
LB-63	16-63	SJ65/33	55AC	150
LB-110	20-110	SJ75/33	75AC	180
